slpanel

홈페이지: https://github.com/ch32n/slpanel



Tcl/Tk megawidget that provides animated, collapsible side panels.

애니메이션이 적용된 접고 펼수 있는 사이드 패널을 제공하는 Tcl/Tk 메가위젯입니다.

package require slpanel

set buttonFrame   [ttk::frame .bf]
set toggle1 [ttk::button $buttonFrame.b1 -text "toggle 1"]
set toggle2 [ttk::button $buttonFrame.b2 -text "toggle 2"]
set close   [ttk::button $buttonFrame.b3 -text "close all"]

grid $buttonFrame -row 0 -column 0 -sticky nsw
grid $toggle1     -row 0 -column 0 -sticky nw
grid $toggle2     -row 1 -column 0 -sticky nw
grid $close       -row 2 -column 0 -sticky nw

# create sliding panel container
set slPanel [slpanel::create .slPanel]
grid $slPanel -row 0 -column 1 -sticky nesw

grid rowconfigure     . 0 -weight 1
grid columnconfigure  . 1 -weight 1

# get sliding panel main frame
set mainFrame  [$slPanel getmainframe]
grid rowconfigure     $mainFrame 0 -weight 1
grid columnconfigure  $mainFrame 0 -weight 1

# create canvas on sliding panel main frame
set maincFcanv [canvas $mainFrame.mCanvas -background white]
grid $maincFcanv -row 0 -column 0 -sticky nesw


# add 2 sliding panels
set slFrame1 [$slPanel add sl1 -speed 130 -close 0.2 -anchor e -open 0.5]
set slFrame2 [$slPanel add sl2 -speed 10  -anchor e -open [winfo pixels . 7c] ]

# bind sliding panel frames virtual events on state change
foreach slFrame [list $slFrame1 $slFrame2] {
	bind $slFrame <<slChange>>     [list puts "Started state change on slFrame: $slFrame new state: %d"]
	bind $slFrame <<slChangeDone>> [list puts "State change done on slFrame: $slFrame new state: %d"]
}

#create widgets in sliding panels
set maincFcanv1 [canvas $slFrame1.slCanvas1 -background red]

grid $maincFcanv1 -row 0  -column 0 -sticky nesw
grid rowconfigure    $slFrame1 0 -weight 1
grid columnconfigure $slFrame1 0 -weight 1


set maincFcanv2 [canvas $slFrame2.slCanvas2 -background green]

grid $maincFcanv2 -row 0  -column 0 -sticky nesw
grid rowconfigure    $slFrame2 0 -weight 1
grid columnconfigure $slFrame2 0 -weight 1

# close sliding panels when button1 click on main frame
bind $maincFcanv <Button-1> [list $slPanel closeopened]

# configure buttons
$toggle1 configure -command [list $slPanel togglepanel sl1]
$toggle2 configure -command [list $slPanel togglepanel sl2]
$close   configure -command [list $slPanel closeopened]

slpanel-main.zip

0.01MB
